CPD50L1
and we will send you an official quotation.
4-wheel Li-Ion Counterbalance Forklift 5000kg. High ground clearance and big tires perfect for handling and traction in every environment. Overhead guard height (h6) = 2250mm and dedicated mast for loading in containers. Shorter l2 and smaller turning radius providing maneuverability in confined spaces. 80V Li-Ion battery grant efficiency, long autonomy and opportunity charging.
New appearance combining both practical and aesthetics design
CPD50L1 reflects both practicality and beauty. The internal lay-out has been optimized,
resulting in shorter l2 of 2900mm and a tighter turning radius of 2675mm. The compact size makes it easy to
maneuver in confined spaces.
The bolted overhead guard offers maximum flexibility for retrofit or replacement and the height of 2250mm
combined with triplex 4,5 meters elevation allows for goods transportation in standard containers.
Fast travel speed for maximum efficiency
Compared to the classic CPD50F8, the travel speed of the
CPD50L1 is improved to 16/18km/h, speeding up warehouse
turnover and increase transport efficiency.
Joystick option for fatigue-free operation
The CPD50L1 can be fitted with hydraulic joystick controls
instead of mechanical levers. Positioned at the end of the
armrest, fingertip operation is possible, improving the operator
ergonomics with the following controls: all fork hydraulic
control including the 4th way, driving direction (F-N-B), horn,
emergency stop button.
ENGINE
Electric
MAST TYPE
-
LIFTING HEIGHT
3,000 mm
ENGINE TYPE
Li-Ion
16/18km/h
2675mm
5000kg
